Planet Gates 0
Universal Motorcycle Meter Speedometer LED Digital Dashboard 12000RPM Gauge Tachometer Panel Motor Odometer Display Y Bracket
Planet Gates
€45.85 EUR
Color
with W bracket
with 2pcs bracket
with Z bracket
with Y bracket
only gauge no holder
with sensor

Description

SPECIFICATIONS

Brand Name: RYSJM

Hign-concerned Chemical: None

Origin: Mainland China

Item Weight: 0.39

Item Diameter: 5.55

Material Type: plastic

External Testing Certification: ce

Item Length: 5.55

Special Features: Motorcycle Speedometer

Item Width: 1.81

Model Name: Motorcycle digital dash universal

Item Height: 5

Material Type: plastic

Special Features: LCD

Speed: 0-199km/h

Operating Voltage: 12V DC

Tachometer: 0-12000r/min

Voltmeter: 8-16V

Choice: yes

semi_Choice: yes

Features:

-5-bars of oil v-olume display, when the oil level is not connected, the working voltage is displayed.

-With 1-6 gear l-iquid crystal display.

-With white backlight, the dial mileage is clearly displayed whether you are driving at night or during the day.

-The function includes: speedometer, Odometer, RPM, Fuel Gauge, the LCD screen is very clear, the viewing angle is large and the soft looking, relieve the eye fatigue.

-Exquisite and smooth, s-afe. Sealed, waterproof.

-Fits most motorcycle models.

Descriptipn:

1.Max speed : 199km/h

2.Max trip: 999.9km

3.Max rpm:1200 rpm

4.blue wire ~High beam

5.yellow-red ~4 level

6.blue-red~2 level

7.blue-white~RPM

8.orange~left turning light

9.green~power

10.black~positive electrode

11.yellow-voltage 5v

12.brown-white~5 level

13.green-black~3 level

14.pink~1 level

15.red~speed

16.green-red~ N level

17.light blue~right turning light

Specifications:

Color: black

Material: plastics+metal

Screen size: 103 * 25mm

Item size: 141 * 46mm
