433 mhz Wireless RF Remote Control Switch EV1527 Learning Code 4CH Relay Receiver Module and On Off Transmitter For DIY Kit
Planet Gates
€3.53 EUR
Color
1M

Description

SPECIFICATIONS

Brand Name: WenQia

Use: Universal

Use: Lighting

Use: Electric Door

Use: Automated curtains

Use: SWITCH

Origin: Mainland China

Wireless Communication: RF

Support APP: No

Certification: CE

Certification: RoHS

Frequency: 433 MHz

Channel: 2

Package: Yes

Model Number: RX470

Transmitter Working voltage: DC 2-3.6V

Receiver Working voltage: DC 2.2~5V

Quiescent Current: 1uA

transfer rate: 20KHz

Transmitter Size: 16* 12 * 6(mm)

Receiver Size: 30*9*6 (mm)

Working temperature: -30~+80 degrees

Transmit deviation: +/- 7. 5KHZ / narrow-band emission

Transmit Sensitivity: larger than 11dBm

RF Operating mode: ASK /OOK superheterodyne wireless reception

Max current: 2.1mA

Frequency band: +/- 150KHz

Receiving Sensitivity: -108dB




433 mhz Wireless RF Remote Control Switch EV1527 Learning Code 4CH Relay Receiver Module and On Off Transmitter For DIY Kit
Product Application Area
Remote control switch, receiver module, motorcycles, automobile anti-theft products, home security products, electric doors, shutter doors, windows, remote control socket, remote control LED, remote audio remote control electric doors, garage door remote control, remote control retractable doors, remote volume gate, pan doors, remote control door opener, door closing device control system, remote control curtains, alarm host, alarm, remote control motorcycle remote control electric cars, remote control MP3.
Applications

  • 1.wireless power switch, socket, remote control switch, receiver module,

  • 2. access control, electric cars, motorcycles, automobile anti-theft products, remote door openers, closers control system

  • 3. security, surveillance systems, home security products, electric doors, alarm host, alarm

  • 4. rooms controls, shutter doors, windows, remote control socket, remote control LED, remote audio remote control electric doors, garage door remote control, remote control retractable doors, remote rolling gates, sliding door

  • 5. smart home products, remote control curtains, remote MP3, audio



Package include

Package List 1:

1 * Receiver module 433Mhz(RX480E)+1 * 433Mhz remote control


Package List 2:

1 * Receiver module 433Mhz(RX480E)


Package List 3:

1 * 433Mhz remote control

  Technical Data

  • Working Voltage : DC3.3~5V

  • Quiescent Current : ≤5mA

  • Working Frequency: 433MHz

  • Receive Sensitivity: -108dB

  • Receive Distance:  15 meters above

  • Frequency band: ±0.2MHz

  • Working Temperature : -25~75 degrees

  • Working mode:Point move, self-locking, interlocking

  • The output: 4 channel CMOS level signal Corresponding to the remote control ABCD 4 buttons.


Pins Instruction
GND : groud or negative pole
+V : DC3.3~5V input
D0: Data output
D1: Data output
D2: Data output
D3: Data output
VT: Output


Application example

Working Modes
Inching mode:Press and hold A button,this relay will work;Release A button,this relay will stop.
Self-Lock Mode:Press A button,the relay will work;press A button again,this relay will stop.
Interlocked mode:Press A button,the relay will work;press B button again,this relay will stop,second relay will work.

How to program
Inching mode:Press the learn button 1 time,press A once ,succeed.
Self-Lock Mode:Press the learn button 2 times,press A once ,succeed.
interlocked mode:Press the learn button 3 times,press A once ,succeed.

Clean Data
1. Press learning button 8 times, LED flashes 7 times,succeed.
