HD5 / HD6 / HD7 / HD8 / HD9 5/6/7/8/9inch Carbon Fiber Quadcopter Frame Kit with 5.5mm Arm For APEX-HD APEX FPV Freestyle RC Racing Drone

With the release of DJI’s new digital HD system and the emergence of real low-latency HD video, there has never been a more exciting time to be flying FPV.

The DJI HD Apex is a variant of the base frame which perfectly houses and protects the DJI Air Unit. By changing only the top and upper main plates of the Apex it becomes the perfect platform for anyone wanting to experience a HD video feed.

The Apex shatters the glass ceiling in frame design.

Through a process of continuous refinement and always striving to improve Impulse RC has created a new breed of freestyle frame. The Apex does not compromise in stiffness or durability, so you never have to choose between confidence and performance.

Unique design elements new to the FPV world make your build and maintenance more simple than ever before. Toughness of the frame itself is increased while also offering much better protection for your investment in-flight electronics.

This is what you have been waiting for!

Innovations include durable, high-qualityabrasion-resistant glass-filled nylon molded parts by HQ Prop (skids, bumpers, antenna mounts), unique arm design allowing for more strength and simple maintenance - arms can be decoupled from frame with just 2 bolts and will not disturb electronic stack. Please see Apex page at Impulse RC for even more features and details.

Specifications :

• Arms: 5.5mm

• Key: 5mm

• Lower Main: 2.5mm

• Upper Main: 2mm

• Top: 2mm

• Camera Sides: 2mm

• Wheelbase: 5inch 225mm/ 6inch 260mm/ 7inch 295mm

STANDOFF HEIGHT

• Front: 28mm

• Rear: 20mm

weight:147g(5inch)

APEX-DC /

APEX-DC

HD 5inch 250mm Carbon Fiber Frame kit

Parameter:

Propeller: 5Inch

Weight about: 163g

Wheelbase: 250mm

Arms plate: 5.5mm

Top plate: 2.0mm

Bottom plate: 2.5mm

Side plate: 2.0mm

UNIQUE ARM GEOMETRY

The Apex DC is a variation on the typical 'dead cat' frame which we have modified to keep the front and rear motors aligned, allowing us to maintain the much loved compressed-x geometry in the motor layout.

This ensures the frame remains balanced and flight characteristics are not compromised, unlike the classic 'dead cat' design which moves the rear motors closer to the body and severely impacts handling.

A major drawback of the Caddx Vista system is that the body of the unit is grounded, this can cause the conductive carbon fiber plates and frame hardware to be grounded too. In an ideal world this is not necessarily a problem, however in the real world it's an accident waiting to happen.

By modifying only the upper and lower main plates we retained full compatiblity with regular Apex arms, using standard 5" arms at the front and standard 6" arms at the back.

Included with the ApexDC are newly redesigned 3D printed insulation inserts. This keeps the camera firmly locked in place and reduces vibrations, whilst ensuring it is electrically isolated from the frame.
